Tenzo Bellacio Extenza 3-Function Thermostatic Shower Valve Trim, Smaller Knurled - F-BET43-F

Tenzo Bellacio Extenza 3-Function Thermostatic Shower Valve Trim, Smaller Knurled - F-BET43-F

The finished trim for the Bellacio Extenza 3-function high-flow thermostatic valve, for a wall where the rough-in is already in place.

What's included

• Bellacio-F Extenza valve trim, 3 functions, thermostatic (F-BET43-F): escutcheon plate, levers and cartridge trim

Not included

• Extenza rough-in valve body, 3 functions (R-43)

Features

• Trim only, every visible above-surface part, finished to match.
• Extenza is Tenzo's 3/4" high-flow platform: 45 L/min [12 gpm] against the 1/2" T-Box's 30 L/min [7.9 gpm], the headroom a three-outlet shower needs.
• Three independent shut-off valves, one per outlet, with outlets on each side of the body. Each opens, closes and throttles on its own rather than sharing a diverter, so any combination can run together.
• Four controls on the trim plate: three levers for the three outlets, and a lower lever on a graduated temperature dial.
• Thermostatic cartridge holds the set temperature against both pressure and supply temperature changes, and shuts off if the cold supply fails.
• Fine diamond knurl on the trim handles and the base collars, the same pattern cut at a much smaller pitch.
• F-BET43-C is the same trim with the larger knurl, at the same price.
• Solid brass.
• Eight finishes. Five are two-tone; the accent colour applies to the knurled detailing.

Specifications

• Room: Bathroom
• Product Type: Shower Valve Trim
• Collection: Bellacio (Tenzo Signature)
• Style: Contemporary
• System: Extenza
• Valve Type: Thermostatic, high flow
• Valve Size: 3/4"
• Functions: 3
• Shut-Off Valves: Three, with outlets on each side
• Valve Flow: 45 L/min [12 gpm] @ 60 psi
• Supply Connection: 3/4" NPT female (on the rough-in)
• Installation Depth: 9 to 11.5 cm [3-1/2" to 4-1/2"]
• Supplied As: Trim only, no rough-in
• Material: Solid brass

Good to know

• The rough-in is not included. Ordered complete with the rough, this is BET43-F.
• Order this version only where the rough is already set in the wall and the finish is being changed or completed.
• On Extenza the thermostatic cartridge (CAR-VNT-T34-07, Vernet) and the shut-off cartridges (CAR-HA-SO34-108-01) sit in the rough-in body. This trim is the plate, the levers and the cartridge trim.
• The Extenza rough is specified by function count, so this 3-function trim goes with an R-43 body. Check the rough in the wall before ordering.
• The Extenza rough is a 3/4" body and needs a wall cavity 9 to 11.5 cm [3-1/2" to 4-1/2"] deep.
• F-BET44-F is the four-outlet version of the same trim.
• On two-tone finishes the first colour is the body, the second the knurled detailing.

Certifications & Warranty

• ASME A112.18.1 / CSA B125.1
• Limited lifetime warranty
