A floor-mounted bath faucet with a separate handshower, pressure-balanced controls and an included Easy-fit installation system.

Features

• Solid brass body.
• Concealed laminar aerator delivers a clear water stream.
• Scale-resistant aerator pivots through 10°.
• Adjustable stop limits the maximum temperature setting.
• Pressure-balance cartridge ABCA56084.
• One lever adjusts volume and temperature.
• Handshower supplied with a 5-foot double-helix hose.
• Front-mounted pull-button diverter selects tub spout or handshower.
• Easy-fit installation system supplied.
• 1/2" water connection.
• Tub spout flow: 5 gpm (19 L/min).
• Handshower flow: 1.8 gpm (6.8 L/min).

Specifications

• Room: Bathroom
• Product type: Floor-mounted tub filler
• Collection: Must
• Model: 56085
• Control: Single lever; two-way diverter
• Material: Solid brass
• Overall height: 37" (940 mm)
• Faucet height: 36 5/8" (930 mm)
• Spout outlet height: 34"
• Overall depth: 11 9/16" (294 mm)
• Spout reach: 7 3/4" (197 mm)
• Handle length: 5 1/8" (130 mm)
• Handshower length shown: 6 7/8" (174 mm)
• Column diameter: 2 1/8" (54 mm)
• Base diameter: 4 1/8" (105 mm)
• Connection: 1/2"
• Flow: tub spout 5 gpm; handshower 1.8 gpm
• Hose length: 5 feet
• Recommended floor opening: diameter 2 1/2" or less
• Supply connection depth below finished floor: 1/2" minimum, 2" maximum without extensions
• Arrange hot and cold inlets close together; their orientation does not determine the final spout direction.

Included Components

• Must 56085 tub filler with lever, cartridge and diverter.
• Handshower and 5-foot double-helix hose.
• Easy-fit installation system.

Required for Installation

No separately purchased, model-specific rough-in is specified. If supply connections are deeper than 2", the installation guide requires commercially available standard male-to-female extensions; no manufacturer part code is specified.

Certifications

• ASME A112.18.1 and CSA B125.1
• ADA compliance
• EPA WaterSense: handshower only
